22
User manual
GYSFLASH 107.24 CNT FV
Translation of the original
instructions
• Abnormal undervoltage protection:
This protection prevents the risk linked to possible short circuits or battery being too damaged. The charger will automatically stop if
the voltage is abnormally low for more than 10 minutes.
TESTER MODE
General navigation :
1 Use the arrows to select the test to be performed
Test
Voltage Test
Engine start
T
est
Alternator Test
2 Press the START/STOP button to start the test
• Voltage test:
This mode allows you to view the voltage at the terminals of the charging clamps and thus use
your GYSFLASH as a voltmeter, in order to measure the battery voltage.
Voltage Test
12.5
v
• Start-up test:
The purpose of this mode is to evaluate the state of a vehicle starting system (starter + battery) when the engine is turned on. This
test must be done with the battery connected to the vehicle.
1 Use the arrows to select the nominal voltage of the vehicle battery
Test
Voltage Test
Engine start
T
est
Alternator Test
2 Press the SELECT button to conrm
3 Connect the clamps to the vehicle battery
4 Start the engine by turning the ignition key
5
The charger automatically detects the engine start attempt and runs a calculation algorithm
to determine the state of the start system.
Test result: The charger indicates the minimum value of the battery voltage perceived during
the engine start phase, as well as the status of the start system in the form of a gauge.
Engine start Test
Umin
12.5
v
• Alternator test :
This mode is used to determine the condition of the alternator in the vehicle. This test is performed on a vehicle with the engine
running.
1 Use the arrows to select the nominal voltage of the vehicle battery
Test
Voltage Test
Engine start
T
est
Alternator Test
2 Press the SELECT button to conrm
Test result: The charger indicates the voltage provided by the vehicle alternator, as well the
alternator status in the form of a gauge.
Alternator
Test
13.5
v
