GPP-1323/GPP-1205 User Manual
92
R_V Slew Rate / F_V Slew Rate Setting Range
Model
Max. Value
Min. Value
GPP-1323
0.0001 V/ms
0.04 V/ms
GPP-1205
0.0001 V/ms
0.04 V/ms
Mode
It sets basic power function or Load mode function.
Load Mode
The GPP-1000 series models have additional Load
function with 2 modes: CV (Constant Voltage) and CC
(Constant Current), all of which can be selected through
the function keys on the front panel.
Measurement
Measure
Average
It sets the speed level of display sampling for the
measure average setting. More the average numbers
(High), slower the display update. By contrast, the Off
option indicates max sampling average and thus with
the lowest speed in display update.
1. Press the Menu key followed by scrolling
knob key to move to Measurement field.
2. Click knob key to enter the Measurement
page. Scroll knob key to move to Measure
Average field followed by clicking knob key
to enter the field.
