OPERATION
63
Save
It saves a select sequence script into either internal
memory or the connected USB disk.
Save From
Edit
To select currently edited script as a source
of script to be saved.
SEQU_
X.csv
If connected USB disk contains saved
scripts, the files are available to select.
Save To Internal
File
X.csv
To save the selected source script into a
select internal memory from no. 1 to 5.
Save To USB
SEQU_
X.csv
To save the selected source script into the
USB disk from no. 001 to 255.
Load
It loads a select sequence script from either connected
USB disk or internal memory. Note that when USB disk
is plugged in, memory from USB disk will prioritize
over internal memory.
File X.csv /
SEQU_X.csv
To load script from USB disk
(SEQU_X.csv) or internal
memory (File X.csv).
Note
When there is any issue occurred from settings, GPP-
1000 series will not be able to run sequence script. The
error code along with warning message will be shown
within the prompt message box when Run filed is
enabled.
Sequence Step Edit Settings
Backgroun
d
This section mainly introduces the settings within the
Sequence Edit page, which is used to edit several
parameters for each step.
Step
To select which step to be edited. The available
option(s) depends on the total step setting.
Step
1 to 999
