OPERATION
61
Sequence Test
This section describes how to use the Sequence function to edit, run,
load and save sequence scripts for automated testing. The sequence
function is useful if you want to perform a number of tests
automatically. The GPP-1000 sequence function can store up to 5 test
scripts in internal memory and also into the connected USB disk.
Each test script can also be programmed in a scripting language. For
more information on how to create sequence scripts via programs,
please contact GW Instek.
Sequence Script File Format
Backgroun
d
The sequence script files are saved in the *.csv file
format. When saving script file into internal memory,
each file is saved as file X.csv where X is the file number
from 1 to 5.When saving script file into the USB disk,
each file is saved as SEQU_X.csv where X is the file
serial number from 1 to 255.
Sequence Script Settings
Backgroun
d
This section mainly introduces the settings within the
Sequence page.
Run
It runs sequence script automatically. A script can be
saved in or loaded from the internal memory or USB
disk. Once the Run field is turned On, return to the
main display followed by pressing Output key to
initiate the set sequence script.
Run On, Off
Total Step
It determines the total steps for a sequence script. Each
step can be edited from the Edit field.
Total Step 1 to 999
