GPP-1323/GPP-1205 User Manual
138
To use GPIB, the optional GPIB option (GW Instek part number:
Option 1) must be installed. This is a factory installed option and
cannot be installed by the end-user. Only one GPIB address can be
used at a time.
Configure
GPIB
1. Ensure the GPP-1000 is off before proceeding.
2. Connect the GPIB cable (GW Instek part
number: GTL-258) from a GPIB controller to the
GPIB port on the GPP-1000.
3. Turn the GPP-1000 on.
4. Set the GPIB Address setting per application.
Page
104
5. The indicator will be shown when a remote
connection has been established.
GPIB
constraints
●Maximum 15 devices altogether, 20m cable length,
2m between each device
●Unique address assigned to each device
●At least 2/3 of the devices turned On
●No loop or parallel connection
GPIB Function Check
Backgroun
d
To test the GPIB functionality, National Instruments
Measurement and Automation Explorer can be used.
This program is available on the NI website,
www.ni.com., via a search for the VISA Run-time
Engine page, or “downloads” at the following URL,
http://www.ni.com/visa/
Requireme
nts
Operating System: Windows XP, 7, 8, 10
