Parallel/Series Operation
123
Backgroun
d
When connecting GPP-1000 power supplies in series,
up to 4 units can be used in series and all units must be
of the same model. When operated in series, the power
supplies can be used to increase the voltage output or
setup the power supplies to output both positive and
negative polarities. Series operation only requires
configuration of the slave, the master unit remains in
local mode.
Limitations
Display
current. The total current is the sum of the units .
OVP/OCP
The master unit can shut down the slave unit when
OVP/OCP is tripped on the master unit .
OVP and OCP level is determined by the master
OVP and OCP level. The OVP and OCP level on the
slave unit is ignored.
Bleeder Control
The Master unit is used to control the bleeder
settings. The bleeder resistor is always turned on for the
slave unit in series mode.
