Parallel/Series Operation
119
Limitations
Display
Only the master unit will display the voltage and
current. The total current is the sum of the units .
OVP/ OCP
The master unit can shut down the slave unit when
OVP/OCP is tripped on the master unit.
OVP and OCP level is determined by the master
OVP and OCP level. The OVP and OCP level on the
slave unit is ignored.
Bleeder Control
The Master unit is used to control the bleeder
settings. The bleeder resistor is always turned off for the
slave unit in parallel mode.
Output
Voltage/
Output
Current
Number of parallel units:
Model
1 unit
2 units
3 units
4 units
GPP-1205
20 V /
5 A
20 V /
10 A
20 V /
15 A
20 V /
20 A
GPP-1323
32 V /
3 A
32 V /
6 A
32 V /
9 A
32 V /
12 A
Parallel Connection
Remote
Interface
Connection
1.Master unit connect the USB cable to the rear panel
USB A port. The other end is connected to the USB HUB
B port.
2. Slave unit connect the USB cable to the rear panel
USB B port. The other end is connected to the USB HUB
A port.
3. Set the USB Device Class setting as CDC.
4. The indicator will be shown when a remote
connection has been established.
Parallel
Output
Connection
If grounding the positive or negative terminals to the
reference ground, be sure to ground the appropriate
terminal on each unit (either positive or negative).
