GPE-1326A/2323A/3323A/4323A Series User Manual
42
3. You can use the CH1/CH4 key
to toggle to CH1(① appears on
the LCD display).
4. Use the voltage and current
knob to set the CH1 output
voltage and current level.
(CH2 voltage is the same as
CH1 value)
5. You can use the CH2/CH3 key
to toggle to CH2 (② appears
on the LCD display).
6. Use the current knob to set the
CH2 output current level.
7. Press the Output key to turn
on the output. The Output key
will be lit.
Refer to the CH1 (Master) meter and indicators for
the output level and CV/CC status.
CH1 (Master)
voltage level
CH1 meter reading shows the
output voltage.
CH1 (Master)
current level
CH1 meter reading shows the
output current.
Refer to the CH1/CH2 meter and CH2 indicators
for the output level and CV/CC status.
CH2 (Slave)
voltage level
The CH2 meter reading shows
the output voltage.
CH2 (Slave)
current level
The CH2 meter reading shows
the output current.
GPE-4323
GPE-4323
