12

① Menu key (MENU):

Press the MENU button to enter the menu setting screen → Rotate [Knob 1] to

select the item → Press [Knob 1] to enter the item setting screen → Set the

parameters of the item by pressing or rotating [Knob 1] → Press [BACK] to go up the

menu.

DMX SETTINGS (Figure 1): Set the DMX

parameters, [address (001-512)] and

configure the mo mode [(8bit/16bit)].

DIM CURVE (Figure 2): Set the dimming

curve, [ linear / logarithmic / Figure2

exponential / S curve ].

WL SETTINGS (Figure 3): RF channel

settings, RF switch, Bluetooth switch,

Bluetooth reset.

STUDIO (Figure 4): Set the studio mode

and non-studio mode.

Studio mode: power off and turn the light

back on, restore the lighting mode and

parameters before the

power failure.

Non-Studio mode: power off and turn the

light back on, restore. Factory set the

default lighting mode

and parameters.

FREQUENCY SETTINGS (Figure5): Set the

dimming frequency.

FUNCTION INTRODUCTION &

INSTRUCTIONS FOR USE

Figure1

Figure2

Figure3

Figure4

Figure5

Press the MENU button to enter the menu setting screen → Rotate [Knob 1] to

select the item → Press [Knob 1] to enter the item setting screen → Set the

parameters of the item by pressing or rotating [Knob 1] → Press [BACK] to go up the

menu.

DMX SETTINGS (Figure 1):

Set the DMX parameters, [address (001-

512)] and configure the mode [(8bit/16bit)].

DIM CURVE (Figure 2):

Set the dimming curve, [ linear / logarithmic

/ exponential / S curve ].

WL SETTINGS (Figure 3):

RF channel settings, RF switch, Bluetooth

switch, Bluetooth reset.

STUDIO (Figure 4):

Set the studio mode and non-studio mode.

Studio mode: power off and turn the light

back on, restore the lighting mode and

parameters before the power failure.

Non-Studio mode: power off and turn the

light back on, restore. Factory set the

default lighting mode and parameters.

FREQUENCY SETTINGS (Figure5):

Set the dimming frequency.
