WWW.GVISION-USA.COM
GVISION USA, INC. 30398 Esperanza, Rancho Santa Margarita, CA 92688 / Phone. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com
41
4) Protocols - By Ethernet Port (Option - Network Sub Board)
To set up the parameters to monitor, transfer the following instruction.
- Transport Layer : TCP
- Port : 5000
- Command : DCOM (Ethernet CMD) + Serial CMD
--> ASCII : DCOM
HEX : 0x44 0x43 0x4F 0x4D
Virtual Remote Control
Example ) Key Power - Set ID 01
Setting Parameters to AD BOARD
Example ) Switch to DP source - Set ID 01
PC -> Monitor
Ethernet CMD(4Bytes) Serial CMD(6Bytes)
0x44 0x43 0x4F 0x4D 0x88 0x01 0xFE 0x01 0xF5
Monitor -> PC
(Response)
0x44 0x43 0x4F 0x4D
Ethernet CMD(4Byte)
0xF0
Serial CMD(1Byte)
0x01
PC -> Monitor
Ethernet CMD(4Bytes) Serial CMD(6Bytes)
D C O M 0x88 ID(0~0xFE
)
FE PARM. VALUE 0xF5
Monitor -> PC
(Response)
D C O M
Ethernet CMD(4Byte)
0xF0
Serial CMD(1Byte)
PC -> Monitor
Ethernet CMD(4Bytes) Serial CMD(6Bytes)
0x44 0x43 0x4F 0x4D 0x88 0x01 FD 11 0xF4
Monitor -> PC
(Response)
0x44 0x43 0x4F 0x4D
Ethernet CMD(4Byte)
0xF0
Serial CMD(1Byte)
PC -> Monitor
Ethernet CMD(4Bytes) Serial CMD(6Bytes)
D C O M 0x88 ID(0~0xFE
)
FD Key Code. 0xF4
Monitor -> PC
(Response)
D C O M
Ethernet CMD(4Byte)
0xF0
Serial CMD(1Byte)
