5. Video Wall Settings
- This menu item is for MULTI VISION model.
1. Press the MENU button and then button to select the Video Wall Settings.
2. Press the OK button (or button) and then button to select Second Settings.
3. Press the OK button or button to select Adjustment menu.
4. Press the button to select desired option.
5. Press MENU button or button to return to the previous menu.
Or In order to come out at a time, press the EXIT button.
Video Wall Layout Settings
SetX=1
SetY=1
SetX=1
SetY=3
SetX=3
SetY=2
SetX=2
SetY=2
SetX=1
SetY=2
SetX=3
SetY=1
SetX=2
SetY=1
SetX=2
SetY=3
SetX=3
SetY=3
X Axis
MaxX = 3
Y Axis
MaxY = 3
X Max : Maximum number of column tiles to divide video image. (Support up to 11step)
Y Max : Maximum number of row tiles to divide video image. (Support up to 11step)
X position : Coordinate of video image’s column position.
Y position : Coordinate of video image’s row position.
