11
GB
ENGLISH
Read and understand the operating
instructions before using the
appliance. Familiarise with the
control elements and how to use the appliance
properly. Abide by all the safety measures stated in
the service manual. Act responsibly toward third
parties.
The operator is responsible for accidents or risks to
third parties.
In case of any doubts about connection and operati
-
on refer please to our customer center
Persons o
ver 16 years of age can only workon the
appliance.An exception includes youngsters trained
in order to reachknowledge under supervision of the
trainer duringoccupational education.
This appliance has not been designed to be used by
persons (including children) with reduced physical, sen
-
sory or mental capabilities or with a lack of knowledge
or exper
ience.
Children must be supervised in order not to play with
the machine.
Specied Conditions Of Use
The winch is designed to move and pull heavy loads
in accordance with the technical specications.
The winch must not be used to move xed or
jammed loads or as a lifting device.
Loads may not be pulled diagonally using winches
intended for lifting and lowering suspended weights.
The device is not approved for use in hazardous areas.
The winch must be securely xed and can only run o
a 12V battery suitable for this type of work.
The device must not be powered from a vehicle
cigarette lighter.
Avoid excessive inching (e.g. gi-
ving short pulses to the motor).
Do not use this product in any other way as stated for
normal use. Not observing general regulations in force
and instructions from this manual does not make the
manufacturer liable for damages.
The device is not approved for continuous
operation. It must never be run continuously for
more than ve minutes.
Technical Data
Electric cable winch 1200/ 12 VOLT 1800/12 VOLT
Art. No 55127 55128
Service connection 12 V 12 V
Max. pulling force 900 kg 1800 kg
Max. pulling force with idle pulley 1800 kg 3600 kg
Max. pulling force – oating items 2200 kg 4000 kg
Max. pulling force – travelling items 2700 kg 4500 kg
Safety class III III
Type of protection IP 55 IP 54
Cable length / Cable thickness Ø 9 m/5,5 mm 9 m/5,5 mm
Pulling speed 1 m/min. 1,8 m/min.
Mounting plate 230x125 mm 230x125 mm
Length Cable for remote control / Electric cable 3 m/3 m 3 m/4,5 m
Weight 11 kg 15 kg
Noise details
Sound pressure level L
pA
83 db(A) 82 db(A)
Sound power level L
WA
90 db(A) 89 db(A)
Measured according to EN 14492 ; Uncertainty K = dB (A)
