Ÿ It must be operated by qualified and trained electrical technicians.
Technicians should observe instructions in this manual and local
regulations.
Ÿ When the OLED screen indicates “PV Isolation low”, do not touch the
chassis as a ground fault may have been detected.
Ÿ Beware of high voltages which may cause electric shocks.
Ÿ After turning off the DC switches and the AC breakers, wait for at
least five minutes before performing any operations to avoid risks.
Ÿ Do not use the air pump to clean the fan. Otherwise, the fan may be
damaged.
Ÿ To ensure good dissipation, clean the fan regularly.
Ÿ Ensure the correct polarity of the terminals before connecting the PV
array to the WIT Inverter.
Ÿ If the cable is thick, do not shake the cable terminals after tightening
them. Otherwise, the loose connection may cause overheating and
device damage. Ensure that the terminals are properly connected
before starting the WIT Inverter.
Ÿ Each WIT Inverter must be equipped with an AC circuit breaker.
Multiple WIT Inverters cannot connect to the same AC circuit breaker.
Ÿ Do not connect the load between the WIT Inverter and the circuit
breaker.
Maintenance and replacement:
2.2 Symbol Conventions
Symbol
Description
DANGER indicates a hazard with a high level of risk which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Ÿ Upon receiving the product, check if the contents are intact and
complete. If any damage is found or any component is missing, please
contact your distributor.
Ÿ For the WIT Inverter that will not be put into operation in the future,
you should properly dispose of them by yourself.
Ÿ The maximum PV input voltage cannot exceed 1100V. The battery
input voltage cannot exceed 1000V.
Others:
Symbol
Description
CAUTION indicates a hazard with potential risk which, if not avoided,
could result in minor or moderate injury.
NOTICE indicates that under certain circumstances, improper
operations could result in property damage.
Remind operators to check the instructions before installing or
operating the WIT Inverter.
2.3 Label Description
Symbol
Name
Meaning
High voltage
High voltages exist after the WIT Inverter is
powered on. Only qualified and trained electrical
technicians are allowed to perform operations.
Burn warning
Do not touch a running inverter because it
generates high temperatures on the shell.
Grounding
Indicates the position for connecting the PE
cable.
Delay discharge
mark
Residual voltage exists after the WIT Inverter is
powered off. It takes 5 minutes to discharge to
the safe voltage.
Refer to the
manual
Remind operators to refer to the manual before
installing and operating the WIT Inverter.
DC
Direct Current.
AC
Alternating Current.
3
4
WARNING
DANGER
WARNING
WARNING
DANGER
WARNING
CAUTION
NOTICE
