12.2 DC input terminal parameter

MC4 specification:

2.5mm /14AWG

4mm /12 AWG

6mm /10 AWG

10mm /8AWG

Rated current (90℃

environment)

32A

40A

44A

65A

Nominal system voltage

1000V DC (UL)

1000V DC (TUV)

Contact resistance

0.25mΩ

Protection grade

IP68

Socket contact

materials

Copper, tin

Insulation materials

Thermoplastics UL94 V-0

Ambient temperature

range

-40℃ to +90℃

Wire stripping length

7.0mm (9/32")

Cable casing diameter

4.5 to 7.8mm (3/16" to 5/16”)

12.3 Torque

Upper cover screws

1.3N·m (10.8 lbf·in)

Shell

0.7N·m (6.2 lbf·in)

DC connector

1.8N·m (16.0 lbf·in)

M6 screwdriver

2N·m (18 lbf·in)

Grounding screw

2N·m (18 lbf·in)

12.4 Accessories (optional)

The following table lists the optional accessories for the SPH Inverter. If you need to

purchase any of them, you can contact Growatt or your dealer. The P/N is for reference

only and it is subject to change without notice.

Product name

Description

GROWATT P/N

ShineLink

Used for data logging in EU

MR00.0011200

Used for data logging in Australia

MR00.0011300

ShineWiFi-X

Used for data logging

MR00.0011000

GPRS

Used for data logging

MR00.0011801

SPH 4000

TL3 BH-UP

SPH 5000

SPH 6000

TL3 BH-UP

SPH 7000

TL3 BH-UP

SPH 8000

TL3 BH-UP

SPH 10K

Residual-current

monitoring unit

Yes

General data

Dimensions (W / H /

544*505*198.5mm

Weight

33kg

Operating

temperature range

–25 °C ~ +60 °C(–13 °F ~ +140 °F)

derating >45℃ (113℉)

Noise emission

(typical)

≤35 dB(A)

Altitude

3000m

Self-Consumption

<13W

Topology

Transformerless

Cooling

Natural

Protection degree

IP65

Relative humidity

0~100%

DC connection

H4 / MC4 (Optional )

AC connection

Connector

Battery connection

H4 / MC4 (Optional)

Interfaces

Display

LCD+LED

RS485/CAN/USB

Yes

RF/WIFI/GPRS/4G

Optional

Warranty: 5 / 10

years

Yes / Optional

Standard compliance

Grid regulation

IEC 62040, VDE-AR-N 4105, VDE 0126, UTE C 15-712, C10/C11,

EN50549, CEI 0-21, CEI 0-16, IEC62116, IEC61727, AS/NZS4777,

G98, TOR Erzeuger

EMC

EN61000-6-1, EN61000-6-3

Safety

IEC/EN62109-1, IEC/EN62109-2

Model

Specifications

Note: The SPH can only operate when the PV input is 120V with its power greater than

120W. Otherwise, it will only light up the display.
