12 Product specification

TL3 BH-UP

SPH 4000

SPH 5000

TL3 BH-UP

SPH 6000

TL3 BH-UP

SPH 7000

SPH 8000

TL3 BH-UP

SPH 10K

Nominal AC voltage

230V/400V

Nominal AC

frequency

50/60Hz

Max. output current

6.1A

7.6A

9.1A

10.6A

12.1A

15.2A

THDV

< 3%

Switch time

< 10ms

Battery data (DC)

Battery voltage range

100~550V

Max. charging /

discharging current

25A

Continuous charging

/ discharging power

4000W

5000W

6000W

7000W

8000W

10000W

Type of battery

lithium battery / Lead-acid battery

Capacity of battery

7.68~76.8kWh

Efficiency

Max. efficiency

97.6%

97.8%

98.0%

98.2%

Euro-eta

97.0%

97.2%

97.3%

97.4%

97.5%

MAX. Battery

charge/discharge

efficiency

97.4%

Protection devices

DC reverse-polarity

protection

Yes

Battery reverse

protection

Yes

DC switch

Yes

DC Surge protection

TypeⅡ

Insulation resistance

monitoring

Yes

AC surge protection

TypeⅢ

AC short-circuit

protection

Yes

Ground fault

monitoring

Yes

Grid monitoring

Yes

Anti-islanding

protection

Yes

Model

Specifications

12.1 Growatt SPH inverter specification

SPH 4000

TL3 BH-UP

SPH 5000

TL3 BH-UP

SPH 6000

SPH 7000

TL3 BH-UP

SPH 8000

TL3 BH-UP

SPH 10K

Input data (DC)

Max. recommended

PV power(for module

STC)

3000W*2

3750W*2

4500W*2

5200W*2

6000W*2

7500W*2

Max. DC voltage

1000V

Start voltage

120V

Nominal voltage

600V

MPP voltage range

120~1000V

No. of MPP trackers

2

No. of PV strings per

MPP trackers

1

Max. input current

per MPP

13.5A/13.5A

Max. short-circuit

current per MPP

trackers

16.9A/16.9A

Output data (AC)

AC nominal power

4000W

5000W

6000W

7000W

8000W

10000W

Max. AC apparent

power

4000VA

5000VA

6000VA

7000VA

8000VA

10000VA

Nominal AC

voltage/range

230V/400V; 310~476

AC grid frequency/

range

50/60Hz; 45~55Hz/55~65 Hz

Max. output current

6.1A

7.6A

9.1A

10.6A

12.1A

15.2A

Power factor

(@nominal power)

1

Adjustable power

factor

0.8leading ~ 0.8lagging

THDi

<3%

AC grid connection

type

3W+N+PE

Stand alone (AC power)

AC nominal output

power

4000W

5000W

6000W

7000W

8000W

10000W

Max. AC apparent

power

4000VA

5000VA

6000VA

7000VA

8000VA

10000VA

Model

Specifications

78
