ExportLimit function is used by the user to control the power feeding into the grid.

When this function is enabled, the feeding power to the grid will be equal to or less than

the set value. The purpose of the fail-safe function is to ensure that in the event of a

failure of export limit function, the active power output will drop to the allowable output

within a specified time.

3.LoadFstCtrl has two modes: SiEn and ThEn. If it is set to SiEn, the phase-level power

control function takes effect in LoadFirst mode, the AC power output will operate

according to the exact load consumption in each phase. If it is set to ThEn, the total

three-phase power control function takes effect in LoadFirst mode, the AC power output

will operate according to the total three-phase power consumption.

1.When the ExportLimit is set to ON and the SingleLimit is OFF, the total Export Limit

function takes effect.

2.When the ExportLimit is set to ON and the SingleLimit is ON, the phase-level export

limit function takes effect.

Note:

Ÿ The default value is 0.00%.

Note:

Ÿ The phase-level export limit function will only take effect when the SingleLimit and

ExportLimit are enabled at the same time.

Ÿ The total export limit function takes effect only when ExportLimit is enabled.

7. In the "RS485" menu, you can press Enter to select the RS485 communication mode:

RS485 Seting

WorkMode

Port：Shinemaster

Meter2

VPP

unused

WorkMode

Chart 6.28

Ÿ In ShineMaster mode, SPH will enter parallel mode. At this time, it needs to be equipped

with SEM-E and does not need to be connected to the meter.

Note:

Ÿ In Meter2 mode, SPH allows two meters to be connected. One is used to read the bus

power, and the other is used to read the power of other inverters.

Ÿ In VPP mode, SPH allows access to external controllers to make relevant settings for SPH.

Ÿ The default value is "unused".

8. In the "Country/Area" menu, you can press Enter to configure the grid code (password:

1111)：

VDE0126

…

EN50438

WorkMode

VDE0126

…

Chile

WorkMode

AS4777

…

AU_sa_network

WorkMode

Europe Area

General Area

Australia Area

CEI 0-21

CEI 0-16

WorkModeItaly Area

…

Country/Area

WorkMode

SC : _ _ _ _

If you need to change safety

options , you need key password

Chart 6.29

Note:

Ÿ Default safety regulations are set at the factory.

Ÿ Determine the region according to the factory's safety regulations set in the factory

before delivery, LCD can only set the corresponding region's safety regulations.

9. In the "Dry Contact" menu, you can press Enter to configure the working hours of

external devices, such as the water heater, diesel generator and others:

Heater

WorkMode

D-Time

WorkMode

00:00 – 00:00

WorkMode

Export P: 0000W

WorkMode

00:00 – 00:00

WorkMode

Export P: 0000W

D-Time

D-Export Power

WorkMode

D-Time

WorkMode

00:00 – 00:00

D-time

WorkMode

Min.Soc 00%

D-Bat

WorkMode

OnDelay: 00min

WorkMode

MinRun: 000 min

WorkMode

OnDelay: 00min

WorkMode

MinRun: 000 min

WorkMode

Heater: OK

WorkMode

Generator : OK

WorkMode

TurnOff P: 000W

WorkMode

TurnOff P: 000W

D-Mix

WorkMode

Dry Connect

Generator

Disable

D-Export Power

D-Mix

Save：OK

NO D-Bat

Save：OK

Min.Vbat 00.0V

D-Time: trigger by time

D-Export Power: trigger by output power

D-Mix: trigger by time and output power
