Growatt SPH 4000-10000TL3 BH-UP Handleiding (88 Pagina's)

Handleiding

Chart 6.25

In the battery type, you can choose lithium battery or lead-acid battery.

Mode Change

WorkMode

Battery ：Lithium

Lead -acid

WorkMode

Press “enter ” key to

make sure

Press “enter ” key to

make sure

5. In the "DiagnoseFun (Diagnose Function)" menu, you can run the assembly check upon

completion of installation.

WorkMode

AssemDiag:ON

OFF

WorkMode

Meter1CommFail

WorkMode

Meter1CommTest

WorkMode

Meter1CommPass

WorkMode

M1AssembleTest

WorkMode

M1AssemblePass

WorkMode

BattChrOrDisPass

WorkMode

BattChrOrDisTest

WorkMode

Meter2CommFail

WorkMode

Meter2CommPass

WorkMode

Meter2CommTest

WorkMode

M1AbnormalWire

WorkMode

BattChrOrDisFail

WorkMode

BattChrOrDisFail

Fail

OK

BatFail

M1Fail

OK

Fail

OK

Fail

WorkMode

AssembleDiagOk

Choose “ON” to

the next item

Passed and

displayed for 10s

The test fails

and press OK to

exit

Passed and

displayed for 10s

Only displayed when

RS485-1/-2 set

Meter2 Enable

Passed and

displayed for 10s

Passed and

displayed for 10s

The test fails

and press OK to

exit

The test fails

and press OK to

exit

The test fails

and press OK to

exit

WorkMode

DiagnoseFun

Diagnosis OK and

press OK to exit

Press “enter”

key to make sure

Chart 6.26

4. In "Mode Change", you can press "Enter" to access the setting options:

Note

2. If the test fails, you can press the OK key to exit.

3. When the self-check is complete, please press the OK key to confirm, then exit self-

check.

4. Disconnect the PV, EPS and Load sides, and turn on the battery and grid connection,

then run the DiagnoseFun (Diagnose Function).

1. The LCD screen displays PASS after each test passes. Wait for 10s, and then proceed to

the next test.

If the test fails, please press the OK key and check the following items:

Error Message

Description

Suggestion

Meter1CommFail

Meter1 communication

fault

Check the connection of the

communication cable between Meter

1 and the inverter.

BattChrOrDisFail

The battery cannot charge

or discharge normally

Check if there are Battery or BMS

related error messages on the LCD.

M1AbnormalWire

Meter1 wiring error

Check if the phase sequence of

Meter1 power line is correct.

Meter2CommFail

Meter2 communication

fault

Check the connection of the

communication cable between Meter

2 and the inverter.

6. In the "ExportLimit (Export Limitation)" menu, you can press "Enter" to access the

setting menu:

ExportLimit

WorkMode WorkMode

ExportLimit: ON

OFF

WorkMode

PowerRate:00.0%

WorkMode

Failsafe:ON

OFF

WorkMode

SingleExport :ON

OFF

Press “enter”

key to make sure

Range from 00.0% to

100.0% And the accuracy

is 0.1%; Default value

is 00.0%

Only displayed when

Safety regulations are

G98/G99 and meter mode

Press “down” key

to the next item

WorkMode

LoadFstCtrl:SiEn

LoadFstCtrl:ThEn

LoadFirstControl

Chart 6.27
