Chart 6.22

Chart 6.23

In the "Basic Parameter" menu, you can press "Enter" for over 1s to access the setting

menu:

In the basic Parameter, you can set language (English, Italian, German), system time, Lead-

acid LV (minimum voltage of single battery, 11.5V by default), Lead-acid CC (maximum

battery charge & discharge current , 25A by default), Lead-acid CV (maximum voltage of

single battery, 14.5V by default), Lead-acid Number (number of connected batteries, 12

by default).

2. In the "EPS" menu, you can press "Enter" for 1s to access the setting menu:

WorkMode

Language

WorkMode

English

Italiano

Deutsch

WorkMode

System time

WorkMode

xxxxY/xxM/xxD XX :XX

WorkMode

Lead-acid LV

WorkMode

11.5 V

WorkMode

Lead-acid CC

WorkMode

25 A

三级

WorkMode

Lead-acid CV

WorkMode

14.5V

WorkMode

RS485 Addr

WorkMode

COM Address :

三级

WorkMode

Lead-acid Number

WorkMode

Basic Parameter

WorkMode

Press “Enter” key

more than 1 seconds

to make sure

Press “Enter” key

more than 1 seconds

to make sure

Press “Down ”

key to the

next item

Only display

when battery

type is lead -

acid

Range from 10 to

12V, and the

accuracy is 0.1V

Range from 1 to

25A, and the

accuracy is 1A

Range from 12 to

15V, and the

accuracy is 0.1V

Can only be set to

12/18/24/36

WorkMode

EPS

WorkMode

EPS: Enable

Disable

ACVolt: 230 V

240

208

WorkMode

AC Freq: 50 Hz

Press “down”

key to the next item

Press “enter” key to

make sure

WorkModeWorkMode

N_PE Relay : ON

OFF

WorkModeWorkMode

Bypass: ON

OFF

2. When EPS is enabled and Bypass is set to OFF, EPS port will have voltage output only in

the case of power failure when the ATS will transition the critical loads;

Note:

1. When EPS is disabled and Bypass is set to OFF, EPS port will not have voltage output

under any circumstances;

3. When EPS is disabled and Bypass is set to ON, EPS port also has voltage output when

there is power grid; and during power failure, EPS port will not have voltage output;

4. When EPS is enabled and Bypass is set to ON, EPS port will have voltage output under

any circumstances.

5. When N-PE Relay is ON, the N-PE replay is closed in the off-grid mode, when the EPS-N

line and the EPS-PE line will be connected; and the N-PE replay is open in other

operating modes. When the N-PE Relay is OFF, the N-PE Relay is open all the time.

You can set EPS to "Enable" or "Disable". It is enabled by default. The default AC voltage

is 230V and the default frequency is 50Hz.

3. In the "Priority" menu, you can press "Enter" to access the setting menu:

Chart 6.24

Note:

Ø Time setting range is 24 hours. If the end time is less than the start time, the time-span

crosses midnight.

Ø ”Power Rate" is used to set the power of the battery. The battery power varies based on

the battery type. Therefore, please check the maximum power of the battery you

selected.

WorkMode

Stop SOC: 100%

Stop SOC: 5%

WorkMode

Time

WorkMode

Power Rate: 100 %

Priority

WorkMode

Opt: Load First

WorkMode

AC CHG: Enable

WorkMode

SC : _ _ _ _

WorkMode

00:00 –

00:00

WorkMode

Save ：OK

WorkMode

Time

WorkMode

00:00 –

00:00

WorkMode

Save ：OK

If battery first is chosen

WorkMode

Bat First: OK

If you need to enable AC charging

function, you need key password

Range from 5% to 100%,

and the accuracy

is 1%

Range from 5% to 100%,

and the accuracyis 1%

WorkMode

If Grid first is chosen

Grid First: OK

Range from 5% to 100%,

and the accuracy

is 1%

Range from 5% to 100%,

and the accuracy

is 1%

Press “down”

key to the next item

Press “down”

key to the next item

Choose “OK”

the next item

Choose “OK”

the next item

Bat First

Grid First

NO Disable

WorkMode

If Load first is chosen

Load First：OK

WorkMode

Stop SOC:xx%

Choose “OK” to

the next item

5655
