Chart 6.20

Line A display:

Ø Normal: the SPH is operating properly.

Ø Checking: the SPH is performing self-check. If no fault is detected, it will switch to the

normal mode; otherwise, it will switch to the fault mode.

Ø Programming: the SPH is upgrading the firmware

Ø Standby: the SPH is in standby mode. No fault is detected, but the operating

requirements are not met.

Ø Fault: once a fault is detected, the SPH will be shut down to protect the device.

In normal mode, the LCD screen lights up automatically. You can press the "Up" button

to access the setting menu. Please refer to the chart below:

Line B display:

Ø Vb refers to the voltage of battery. Pm means the monitoring power.

Ø Press "Down" to move to the next item, and "Up" to the previous one.

Ø The work mode is displayed in accordance with the actual operating status.

Note:

WorkMode

Input&Output Para

WorkMode

(Lead acid )Vb:xx.xV

(Lithium)Vb/Cb:xx.xV/xxx%

Battery info

WorkMode

Grid:xxxV /xxHz

WorkMode

EPS:xxxV/xxHz

WorkMode

Po:xxxxW/xxxxVA

UPS/EPS

WorkMode

EPS:xxxxVA

WorkMode

Pbat: (+/-)XXXX W

Battery power

WorkMode

Ec_d:xxxx .x KWh

WorkMode

Ec_a:xxxx.x KWh

WorkMode

Ed_d:xxxx.x KWh

WorkMode

Ed_a:xxxx.x KWh

WorkMode

SerNo :xxxxxxxxxx

Online

BAT Charge Etoday

WorkMode

PL: (+/-)XXXXW

WorkMode

Per_Load: %

Master Power

BAT Charge Etotal

BAT Discharge Etoday

BAT Discharge Etotal

WorkMode

20XX/XX/XX/ XX:XX

WorkMode

Model :xxxxxxxxxx

WorkMode

FW Version :xxxx

WorkMode

Eac_d:xxxx.x KWh

WorkMode

Eac_a:xxxx.x KWh

AC output Etoday

AC output Etotal

WorkMode

Pex: (+/-)XXXXW

WorkMode

Pm: (+/-)XXXXW

WorkMode

Eld_d:xxxx .x KWh

WorkMode

Eld_a:xxxx.x KWh

WorkMode

Etg_d:xxxx .x KWh

WorkMode

Etg_a:xxxx.x KWh

WorkMode

Etu_d:xxxx .x KWh

WorkMode

Etu_a:xxxx.x KWh

WorkMode

Eex_d:xxxx.x KWh

WorkMode

Eex_a:xxxx.x KWh

Extern PvInv Power

WorkMode

MCU:xxxxxx

WorkMode

STM3:xxxxxx

enter

Load_Etoday

Load_Etotal

To Grid Etoday

To Grid Etotal

To User Etoday

To User Etotal

Extern PvInv Etoday

Extern PvInv Etotal

Load Power

offline

Chart 6.21

For inverters to be commissioned in Italy with the grid code of CEI, the Auto Test is

required. For details, please refer to the Appendix.

6.5.4 Setting the working mode

Press the "Enter" key for over 3s to enter the setup mode. You can press "Enter" to

confirm your setting or "ESC" to exit. Please refer to the process flow chart below:

Basic Parameter

WorkMode

Configuration

WorkMode

Priority

WorkMode

EPS

Press “enter” key more than

3 seconds into setup mode

Press “down” key

to the next item

Press “enter” key more

than 1 seconds to make sure

Mode Change

WorkMode

ExportLimit

WorkMode

Auto Test

WorkMode

Default Set

WorkMode

DiagnoseFun

WorkMode

RS485 Seting

WorkMode

Country/Area

WorkMode

Dry Connect

WorkMode

5453
