5.3.2 Installing the SPH inverter

1. Determine the installation position on the wall, ensure that it is suitable for the weight

and dimensions of the inverter.

2. Use the paperboard (installation guide) to determine the hole positions, ensuring that

the paperboard is level.

3. Mark the four hole positions on the wall, then remove the paperboard.

4. Drill four holes (Φ8 mm) at the marked positions to a depth of greater than 55 mm.

8. The installation is complete.

7. Fasten the nuts of the screw sets (as Fig 5.8d shows).

5. Insert four expansion bolts into the holes (Φ8 mm) (as Fig 5.8b shows).

6. Hang the inverter onto the four screw sets (as Fig 5.8c shows).

Figure 5.7

Figure 5.8

a) b)

c)

d)

5.4 Electrical connection

5.4.1 Connecting the PV connectors (Item L and M in the accessory kit)

PV+

PV-

The Inverter Side

Figure 5.9

≥15m

Breaker

Load

PV Array

EPSGrid

Hybrid Inverter

L1

L2

L3

N

AC

Breaker

EPS

Load

Sensor

AC

Breaker

Electrical Grid

DC

Breaker

Electric meter

Battery

18

17
