14
After connecting all wiring, please put bottom cover back by screwing four screws as shown below.
Communication Connection
Please use supplied communication cable to connect to inverter and PC. Follow on-screen instruction to install
the monitoring software. For the detailed software operation, please check user manual of software. The
monitoring software is downloadable from our website www.ginverter.com.
Dry Contact Signal
There is one dry contact(3A/250VAC) available on the rear panel. It could be used to deliver signal to external
device when battery voltage reaches warning level.
Unit Status
Condition
Dry contact port:
NC & C
NO & C
Power Off
Unit is off and no output is powered
Close
Open
Power On
Output is powered from Utility
Close
Open
Output is
powered from
Battery or Solar
Program 01 set
as Utility first
Battery voltage (SOC)< Low DC
warning voltage(SOC)
Open
Close
Battery voltage(SOC) > Setting
value in Program 13 or battery
charging reaches floating stage
Close
Open
Program 01 is
set as SBU or
Solar first
Battery voltage (SOC)< Setting
value in Program 12
Open
Close
Battery voltage (SOC)> Setting
value in Program 13 or battery
charging reaches floating stage
Close
Open
Maintenance
Heat dissipation performance is very important when SPF inverter work under the environment of high
temperature, better heat dissipation can reduce the possibility of SPF inverter failure.
GROWATT SPF series inverters are with IP20 enclosure, which use fan cooling method. To make sure the
system runs properly, please notice the environment temperature should be in 0~55℃ and try installing the
