29
WARNING: Be sure the length of all battery cables is the same. Otherwise, there will be voltage difference between
inverter and battery to cause parallel inverters not working.
You need to connect the cables of each inverter together. Take the battery cables for example: You need to use a
connector or bus-bar as a joint to connect the battery cables together, and then connect to the battery terminal.
The cable size used from joint to battery should be X times cable size in the tables above. “X” indicates the number
of inverters connected in parallel.
Regarding AC input and output, please also follow the same principle.
Recommended AC input and output cable size for each inverter:
Model
Gauge
Torque Value
SPF 3000T HVM-G2
1 * 10 AWG
1.2-1.6 Nm
SPF 6000T HVM-G2
1 * 8 AWG
1.2-1.6 Nm
CAUTION!! Please install the breaker at the battery, PV and AC input side. This will ensure the inverter can be
securely disconnected during maintenance and fully protected from over current of battery or AC input.
Recommended breaker specification of battery for each inverter:
Model
1 unit*
SPF 3000T HVM-G2
100A / 60VDC
SPF 6000T HVM-G2
200A / 60VDC
Recommended breaker specification of PV for each inverter:
Model
1 unit*
SPF 3000T HVM-G2
80A/300Vdc
SPF 6000T HVM-G2
80A/300Vdc
Recommended breaker specification of AC input for each inverter:
Model
1 unit*
SPF 3000T HVM-G2
40A/250Vac
SPF 6000T HVM-G2
60A/250Vac
*If you want to use only one breaker at the battery side for the whole system, the rating of the breaker should be X
times current of 1 unit. “X” indicates the number of inverters connected in parallel.
Recommended breaker specification of AC input with single phase:
Model
2 units
3 units
4 units
5 units
6 units
SPF 3000T HVM-G2
60A/230VAC
90A/230VAC
120A/230VAC
150A/230VAC
180A/230VAC
SPF 6000T HVM-G2
120A/230VAC
180A/230VAC
240A/230VAC
300A/230VAC
360A/230VAC
Note1: You can use 30A breaker for SPF 3000T HVM-G2 for only 1 unit, and each inverter has a breaker at its AC
input. And use 60A breaker for SPF 6000T HVM-G2 for only 1 unit, and each inverter has a breaker at its AC input.
Note2: Regarding three phase system, you can use 4 poles breaker, the rating is up to the current of the
phase which has the maximum units. Or you can follow the suggestion of note 1.
