Je bekijkt pagina 22 van 48
20
LCD Setting
After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press “UP” or “DOWN”
button to select setting programs. Then press “ENTER” button to confirm the selection or ESC button to exit.
Note：When under parallel operation, only can set parameters at the HOST inverter, except for Program 23
which all inverters can be accessed to set value.
Program
Description
Setting Option
01
Output source priority: To
configure load power
source priority
Solar first
Solar energy provides power to the loads as first priority.
If solar energy is not sufficient to power all connected loads, battery
energy will supply power the loads at the same time.
Utility provides power to the loads only when any one condition
happens:
Solar energy is not available
Battery voltage drops to either low-level warning voltage or the setting
point in program 12.
Utility first (default)
Utility will provide power to the loads as first priority.
Solar and battery energy will provide power to the loads only when
utility power is not available.
SBU priority
Solar energy provides power to the loads as first priority.
If solar energy is not sufficient to power all connected loads, battery
energy will supply power to the loads at the same time.
Utility provides power to the loads only when battery voltage drops to
either low-level warning voltage or the setting point in program 12.
BPL priority
Choose BPL, then press ENTER to switch to
Program 90, which is set voltage point to charge
battery
Default 52V, 46V~58V Settable
(Program 21 < Program 90 < Program 20)
Utility energy provides power to the loads as first priority.
If utility energy is not sufficient to power all connected loads, battery
Energy and solar energy will supply power the loads at the same time.
02
Maximum charging current:
set total charging current for
solar and utility chargers.
(Max. charging current =
utility charging current + solar
charging current)
3000W model: Default 80A, 10A~120A Settable
6000W model: Default 80A, 10A~140A Settable
(If LI is selected in Program 5, this program can’t be set up)
