40
Table 3 Charge Mode Specifications
Utility Charging Mode
INVERTER MODEL
SPF 6000 ES PLUS
Charging Algorithm
3-Step
Max. AC Charging Current
80Amp(@V
I/P
=230Vac)
Bulk Charging
Voltage
Flooded Battery
58.4Vdc
AGM / Gel Battery
56.4Vdc
Floating Charging Voltage
54Vdc
Charging Curve
MPPT Solar Charging Mode
Max. PV Array Power
4000W+4000W
Max. PV Input Current
16A+16A
Start-up Voltage
150Vdc±10Vdc
PV Array MPPT Voltage Range
120Vdc~450Vdc
Max. PV Array Open Circuit Voltage
500Vdc
Max. Inverter Back Feed Current To
The Array
0A
Max. PV Charging Current
100A
Max. Charging Current
(AC Charger Plus Solar Charger)
100A
Table 4 General Specifications
INVERTER MODEL
SPF 6000 ES PLUS
Safety Certification
CE
Operating
Temperature
Range
0℃ to 55℃
Storage temperature
-15℃~ 60℃
Humidity
5% to 95% Relative Humidity (Non-condensing)
Altitude
<2000m
Dimension(D*W*H), mm
460*395*132
Net Weight, kg
13.5kg
