Regarding AC input and output, please also follow the same principle.
Recommended AC input and output cable size for each inverter:
Model
Gauge
Torque Value
SPF 6000 ES PLUS
1 * 8 AWG
1.2-1.6 Nm
CAUTION!! Please install the breaker at the battery and AC input side. This will ensure the inverter can be
securely disconnected during maintenance and fully protected from over current of battery or AC input.
Recommended breaker specification of battery for each inverter:
Model
1 unit*
SPF 6000 ES PLUS
200A / 60VDC
*If you want to use only one breaker at the battery side for the whole system, the rating of the breaker should be X
times current of 1 unit. “X” indicates the number of inverters connected in parallel.
Recommended breaker specification of AC input with single phase:
Model
2 units
3 units
4 units
5 units
6 units
SPF 6000 ES
PLUS
100A/230VAC
150A/230VAC
200A/230VAC
250A/230VAC
300A/230VAC
Note1: You can use 50A breaker for SPF 6000 ES PLUS for only 1 unit, and each inverter has a breaker at its AC input.
Note2: Regarding three phase system, you can use 4 poles breaker, the rating is up to the current of the
phase which has the maximum units. Or you can follow the suggestion of note 1.
Recommended battery capacity
Inverter parallel numbers
2
3
4
5
6
Battery Capacity
400AH
600AH
800AH
1000AH
1200AH
WARNING! Be sure that all inverters will share the same battery bank. Otherwise, the inverters will transfer to
fault mode.
