MOD
3000TL3-XA
MOD
4000TL3-XA
MOD
5000TL3-XA
MOD
6000TL3-XA
THDv
THDv≤2%@Rload，THDv≤5%@RCDload
DCV
≤300mV AVG.
Switch time
<500ms
Protection devices
AC surge protection
YES
AC short-circuit
protection
YES
Grid monitoring
YES
Anti-islanding
protection
YES
Residual-current
monitoring unit
YES
String Fuse protection
NO
String monitoring
YES
AFCI protection
NO
General data
Dimensions (W / H / D) in
mm
425*387*147mm
Weight
11.5kg
Operating temperature
range
-25°C ... +60°C
(>45°CDerating)
Noise emission (typical)
≤29dB(A)
Altitude
3000m
Internal consumption at
night
<5.5W
Topology
Transformerless
Cooling
Natural heat dissipation
Electronics protection
degree
IP66
Relative humidity
0~100%
DC connection
H4/MC4(OPT)
AC connection
quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
Model
Specifications
MOD
7000TL3-XA
MOD
8000TL3-XA
MOD
9000TL3-XA
MOD
10KTL3-XA
DC Battery
Compatible battery(only)
ARK-XH HV Battery(7.68kWh~25.6kWh)
APX HV Battery(5kWh~20kWh)
Operating voltage range
600 V ~ 950 V
Max.operating current
18.5A
Max.discharge power
7000W
8000W
9000W
10000W
Max.charge power
10kW
Output data(On-gird)
AC nominal power
7000W
8000W
9000W
10KW
Max. AC apparent
7000VA
8000VA
9000VA
10VA
Nominal AC
voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Max. output current
10.6A
12.1A
13.6A
15.2A
AC inrush current
30A
Max. output fault
current
42.7A
Max. output overcurrent
Protection
42.7A
Power factor(@nominal
power)
>0.99
THDi
<3%
AC grid connection type
3W+N+PE
Efficiency
Max. efficiency
98.60%
Euro-eta
98.10%
Output data(Backup)
Nominal output power
7kW
8kW
9kW
10kW
Max. apparent power
7kVA
8kVA
9kVA
10kVA
Nominal AC output
voltage
230V/400V
Nominal AC output
frequency
50Hz
Max. output current
10.2A
11.6A
13.1A
14.5A
Power factor
0.8 leading to 0.8 lagging
Model
Specifications
48
47
