3.4 Storage of Inverter
3.5 The advantage of the unit
3.3 Size and weight
More detail about the type label as the chart below:
Model
Height (H) Width (W) Depth (D)
Weight
MIN 2500-6000 TL-XH
350mm 13.8inch 375mm 14.8inch 160mm 6.3inch 10.8kg
If you want to storage the inverter in your warehouse, you should choose an appropriate
location to store the inverter.
Ø The unit must be stored in original package , and should be stored in a clean and dry
place, and be protected from dust and water vapor corrosion.
Ø The storage temperature should be always between -25 and +60 . And the
storage relative humidity can achieve to 100%.
Ø If there are a batch of inverters need to be stored, the maximum layers for original
carton is four.
Ø After long term storage, local installer or service department of GROWATT should
perform a comprehensive test before installation.
Ø Max. efficiency of 98.4%
Ø Dual MPP trackers
Ø Type II SPD on DC side
Ø 30% lighter
Ø Storage ready
Ø AFCI optional
Ø Compatible with double-glass bifacial modules
Model Name
MIN 2500 TL-XH MIN 3000 TL-XH MIN 3600 TL-XH
Max input PV voltage
Max input PV current
Start voltage
MPP voltage range
DC nominal input voltage
DC input voltage range
DC Max input/output current
AC nominal voltage
AC grid frequency
Environmental Protection
Rating
Operation Ambient
temperature
500V
500V
550V
13.5A/13.5A
100V
70V~500V
70V~500V 70V~550V
360V~500V
400V
230V
50/60 Hz
2500VA 3000VA 3600VA
11.3A 13.6A 16A
0.8leading…0.8lagging
IP 65
-25...+60℃ (-13...+ 140°F)
with derating above 45°C（ 113°F）
Max. apparent power
Max AC output current
Power factor
17A
Model Name
MIN 4200
TL-XH
MIN 4600
TL-XH
MIN 5000
TL-XH
MIN 6000
TL-XH
Max input PV voltage
Max input PV current
Start voltage
MPP voltage range
DC nominal input voltage
DC input voltage range
DC Max input/output current
AC nominal voltage
AC grid frequency
Environmental Protection
Rating
Operation Ambient
temperature
550V
13.5A/13.5A
100V
70V~550V
360V~550V
400V
230V
50/60 Hz
4200VA 4600VA 5000VA 6000VA
19A 20.9A 22.7A 27.2A
0.8leading…0.8lagging
IP 65
-25...+60℃ (-13...+ 140°F)
with derating above 45°C（ 113°F）
Max. apparent power
Max AC output current
Power factor
17A
Dimensions and weight
10
9
360V~500V 360V~550V
