3.4 Storage of Inverter
3.5 The advantage of the unit
3.3 Size and weight
More detail about the type label as the chart below:
Model
Height (H)
Width (W)
Depth (D)
Weight
MIN 2500-6000 TL-XA
350mm 13.8inch
375mm 14.8inch
160mm 6.3inch
9.1kg
If you want to storage the inverter in your warehouse, you should choose an appropriate
location to store the inverter.
Ø The unit must be stored in original package , and should be stored in a clean and dry
place, and be protected from dust and water vapor corrosion.
Ø The storage temperature should be always between -25 and +60 . And the storage
relative humidity can achieve to 100%.
Ø If there are a batch of inverters need to be stored, the maximum layers for original
carton is four.
Ø After long term storage, local installer or service department of GROWATT should
erform a comprehensive test before installation.
Dimensions and weight
10
9
Model Name
MIN 2500 TL-XA
MIN 3000 TL-XA
MIN 3600 TL-XA
DC nominal input
voltage
400V
DC input voltage
range
360~500V
360~500V
360~550V
DC Max
input/output current
17A
AC nominal voltage
230V
AC grid frequency
50/60 Hz
Max. apparent
power
2500VA
3000VA
3600VA
Max AC output
current
11.3A
13.6A
16A
Power factor
0.8leading…0.8lagging
Environmental
Protection Rating
IP 65
Operation Ambient
temperature
- 25...+60 (-13...+ 140°F)
with derating above 45°C（ 113°F）
Model Name
MIN
4200 TL-XA
MIN
4600 TL-XA
MIN
5000 TL-XA
MIN
6000 TL-XA
DC nominal input
voltage
400V
DC input voltage
range
360~550V
DC Max
input/output current
17A
AC nominal
voltage
230VAC
AC grid frequency
50/60 Hz
Max. apparent
power
4200VA
4600VA
5000VA
6000VA
Max AC output
current
19A
20.9A
22.7A
27.2A
Power factor
0.8leading…0.8lagging
Environmental
Protection Rating
IP 65
Operation Ambient
temperature
- 25...+60 (-13...+ 140°F)
with derating above 45°C（ 113°F）
375
350
160
Ø Max. efficiency of 98.4%.
Ø 40% lighter.
Ø Storage ready.
Ø Compatible with double-glass bifacial modules.
