Growatt MIN 2500-5000TL-XA handleiding
Handleiding
Je bekijkt pagina 28 van 30
MIN
2500 TL-XA
MIN
3000 TL-XA
MIN
3600 TL-XA
MIN
4200 TL-XA
Overvoltage category
AC:III BAT:II Others:I
Cooling
Natural convection
Ingress protection
IP65
Pollution degree outside
the enclosure
3
Pollution degree inside
the enclosure
2
Relative humidity
0~100%
DC connection
VP-D4
AC connection
AC connector
Interfaces
Display
OLED+LED
RS485/USB
Integrated
WIFI/GPRS/4G/LAN/ RF
Optional
Warranty:5/10 years
Yes/ Optional
Model
Specifications
MIN
4600 TL-XA
MIN
5000 TL-XA
MIN
6000 TL-XA
DC input quantities
Nominal DC input voltage
400V
DC input voltage range
360-550V
DC input current
(maximum continuous)
17A
DC output quantities
Nominal DC output voltage
400V
DC output voltage range
360-550V
DC output current
(maximum continuous)
17A
Battery type
Cobalt Free Lithium Iron Phosphate (LFP）
AC output quantities
Rated output power
4600W
5000W
6000W
Rated apparent power
4600VA
5000VA
6000VA
Nominal AC voltage
230V
AC voltage range
160-276V
Norminal AC grid frequency
50/60Hz
AC grid frequency range
45-55Hz/55-65Hz
Rated output current
20.9A
22.7A
27.2A
Max. inrush current
(Peak value/duration time)
＜10A/5ms
Max. output fault current
＜62A/20us
Max.output overload
protection
25A
32A
32A
Backfeed current
0A
Power factor(@nominal power)
>0.99
Power factor range
0.8leading… 0.8lagging
THDi
<3%
AC grid connection type
Single phase(L/N/PE)
AC overvoltage category
Category III
Model
Specifications
