Growatt MID 30-40KTL3-X-AU handleiding
Handleiding
Je bekijkt pagina 31 van 35
Mode
l
Specifications
MID
30KTL3-X-AU
MID
33KTL3-X-AU
MID
36KTL3-X-AU
MID
40KTL3-X-AU
Input data(DC)
Max. recommended PV
power(for module STC)
45000W
49500W
54000W
60000W
Max. DC voltage 1100V
Start voltage 250V
Min. operating voltage 200V
Nominal voltage 600V
MPP voltage range 200-1000V
No. of MPP trackers
3
4
No. of PV strings per MPP
trackers
2/2/2
2/2/2 2/2/2/2 2/2/2/2
Max. input current per MPP
trackers
26A*3
26A*3 26A*4 26A*4
Max. short-circuit current
per MPP trackers
40A*3
40A*3 40A*4
40A*4
Backfeed current to PV
array
0A
Output data(AC)
Rated output power 30000W
33000W 36000W
40000W
Rated apparent power
30000VA
33000VA 36000VA 40000VA
Max. AC apparent 33300VA 36600VA 40000VA 44400VA
Nominal AC voltage/range
230/400V
340-440V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Rated output current
43.5A 47.8A 52.2A
58.0A
Max. output current
50.5A 55.6A
60.6A 67.3A
Max output overload
protection
80A/230V
80A/230V
100A/230V
100A/230V
Max. inrush current(Peak
value/duration time)
41A/2ms
46A/2ms 52A/2ms
57A/2ms
AC inrush current 60A
Max. output fault current(Peak
value/duration time)
113.3A/10us
113.3A/10us 132.2A/10us 132.2A/10us
Max. output fault current 106.1A
106.1A 124.8A
124.8A
Max. output overcurrent
Protection
106.1A
106.1A 124.8A 124.8A
Power factor(@nominal
power)
>0.99
Adjustable power factor
0.8Leading ...0.8Lagging
THDi <3%
AC grid connection type 3W+PE /3W+N+PE
Overvoltage category
PV:II AC:III Others:I
Mode
l
S
pecifications
MID
17KTL3-X1-AU
MID
20KTL3-X1-AU
MID
22KTL3-X1-AU
MID
25KTL3-X1-AU
Max. efficiency 98.75% 98.75% 98.75% 98.8%
Euro-eta 98.5% 98.5% 98.5% 98.5%
Protection devices
DC reverse-polarity protection
YES
DC switch YES
DC Surge protection
typeII OPT
Insulation resistance
monitoring
YES
AC surge protection typeII OPT
AC short-circuit protection
YES
Grid monitoring YES
Anti-islanding protection
Integrated(Active Frequency Drift)
Residual-current monitoring
unit
YES
String Fuse protection
NO
String monitoring
OPT
AFCI protection
OPT
General data
Dimensions (W / H / D) in mm 580*435*230mm
Weight
30.0kg
Operating temperature range
-25°C ... +60°C
(>45°CDerating)
Noise emission (typical)
≤50dB(A)
Altitude
4000m
Internal consumption at night 1W
Topology
Non-isolated
Cooling Smart air cooling
Electronics protection degree
IP66
Relative humidity 0~100%
DC connection
H4/MC4(OPT)
AC connection
Waterproof PG head+OT terminal or quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
55
56
