Growatt MID 10-30KTL3-XH handleiding
Handleiding
Je bekijkt pagina 46 van 55
MID 10KTL3
-XH
MID11KTL3
-XH
MID 12KTL3
-XH
MID13KTL3
-XH
MID 15KTL3
-XH
Insulation resistance
monitoring
YES
AC surge protection
YES
AC short-circuit
protection
Active Frequency Shift
Grid monitoring
YES
Anti-islanding
protection
YES
Residual-current
monitoring unit
YES
String fuse
protection
NO
String monitoring
YES
AFCI protection
Configurable
General data
Dimensions (W / H /
D) in mm
579*433*217.5mm
Weight
30kg
Operating
temperature range
-25°C ... +60°C
(>45°C Derating)
Noise emission
(typical)
≤36dB(A)
Altitude
4000m
Internal consumption
at night
<5.5W
Topology
Transformerless
Cooling
Natural heat dissipation
IP rating
IP66
Relative humidity
0~100%
DC connection
H4/MC4 (OPT)
AC connection
Waterproof PG connector + OT terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
LAN
WIFI/GPRS/4G/RF/
OPT
Model
Specifications
MID 17KTL3
-XH
MID 20KTL3
-XH
MID 25KTL3
-XH
MID 30KTL3
-XH
Input data (DC)
Recommended Max. PV
power (for module STC)
34000W
40000W
50000W
60000W
Max. DC voltage
1100V
Start voltage
200V
Full power voltage range
266V~850V
313V~850V
261V~850V
313V~850V
Nominal voltage
600V
MPPT voltage range
160-1000V
No. of MPPT trackers
3
No. of PV strings per
MPPT tracker
2/2/2
2/2/2
2/2/2
2/2/2
Max. input current per
MPPT tracker
32A/32A/32A
32A/32A/32A
32A/32A/32A
32A/32A/32A
Max. short-circuit current
per MPPT tracker
48A
Backfeed current to PV
array
0A
DC Battery
Compatible battery (only)
APX HV Battery
(5kWh~60kWh)
Operating voltage range
600 V ~ 980 V
Max. operating current
25A/25A
Max. discharge power
17000W
20000W
25000W
29900W
Max. charge power
15000W/30000
W
Output data (on-grid)
Nominal AC power
17000W
20000W
25000W
29900W
Max. AC apparent power
18700VA
22000VA
27500VA
29900VA
Nominal AC
voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Max. output current
24.6A
29A
36.2A
43.3A
AC inrush current
60A
Max. output fault current
74.1A
106.7A
Model
Specifications
8079
