The following safety symbols are used throughout this document to denote important
safety information. Familiarize yourself with the symbols and their meaning before
installing or operating this instrument.
Labels on this product
Symbol convention
Symbols in this manual
DANGER
WARNING
Symbol
Meaning
DANGER indicates a hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE is used to address practices which are not safety relevant.
Information that you must read and know to ensure optimal system
operation.
CAUTION
NOTICE
Information
Symbol
Explanation
Risk of high voltages which might lead to electric shocks
Risk of fire
Risk of burns due to hot surface
Delayed discharge: High voltage exists after the battery is powered
off. It takes 5 minutes to discharge to the safe voltage.
Grounding: indicates the position for connecting the PE cable
Direct Current (DC)
Alternating Current (AC)
Refer to the manual
The inverter complies with the requirements of the applicable EU
directives
CE marking
Do not dispose of the product together with the household waste but
in accordance with the disposal regulations for electronic waste
applicable at the installation site
Definition and interpretation
AC
Abbreviation for “Alternating Current”
DC
Abbreviation for “Direct Current”
PV
Energy
GFCI stands for Ground Fault Circuit Interrupter. It is a safety device for protection
against line-to-ground faults. A GFCI offers protection to users of electrical equipment
against possible fatal electric shock from faulty equipment or accidental grounding.
Power rate
Power
Abbreviation for photovoltaic
Energy is measured in units of Wh (watt-hour), kWh (kilowatt-hour) or MWh (megawatt-
hour). It is a measure of power output over time (energy = power x time). For example,
if the inverter operates at a constant power of 4600 W for 30 minutes and then at a
constant power of 2300 W for another 30 minutes, it would have generated a total
energy output of 3450 Wh in that hour.
Power factor is the ratio between real power (measured in watts) and apparent power
(measured in Volt-Amps). When the current and voltage are in phase, the power factor
is 1.0. In an AC circuit, the power is not always equal to the direct product of volts and
amperes due to reactive components. In order to find the true power of a single-phase
AC circuit, the product of volts and amperes must be multiplied by the power factor.
GFCI
Power is measured in W (watts), kW (kilowatts) or MW (megawatts), describing the rate
at which the electricity is being used at a specific moment.
Power factor
AFCI
Power rate is the ratio of current power fed into the power distribution grid and the
maximum power of the inverter that can be fed into the power distribution grid.
AFCI stands for Arc Fault Circuit Interrupter. It is a protective device designed to
protect against fire hazards caused by arc faults. The Arc Fault Circuit Interrupter can
detect arcs in the circuit and break the supply of electrical power to the circuit.
