9.2 Trouble Shooting
9.2.1 Warning
• It must be operated by well-trained professional electrical technicians
and abide by this manual.
• Normally grounded conductors may be ungrounded and energized
when a PV isolation low is indicated.
• Risk of electric shock.
Warnings identify the current status of the inverter(Max), warnings do not related to a
fault and it does not affect the normal running of the inverter. When a warning with a
number after it appears in the display, it indicates a warning code and is usually cleared
through an orderly shutdown/re-set or a self-corrective action performed by the inverter.
DANGER
Warning
Description
Suggestion
Warning 200
String Fault
1.After shutdown,check the panel is
normal.
2.Contact Growatt.
Warning 201
String abnormal
1.After shutdown,check the panel is
normal.
2.Contact Growatt.
Warning 202
DC SPD warning
1.After shutdown,check the DC SPD.
2.Contact Growatt.
Warning 203
PV Circuit short
1.Check if the PV circuit is short-
circuited.
2.Contact Growatt.
Warning 204
Dryconnect function
abnormal
1.After shutdown,check the dry
Dryconnect wiring.
2.Contact Growatt.
Warning 205
PV Boost driver abnormal
1.Restart inverter.
2.Contact Growatt.
Warning 206
AC SPD warning
1.After shutdown,check the AC SPD.
2.Contact Growatt.
Warning 207
USB Over-Current
1.unplug the U disk.
2.Re-access U disk after shutdown.
3.Contact Growatt.
Warning 208
DC Fuse Open
1.After shutdown,check fuse.
2.Contact Growatt.
Warning 209
PV Voltage High
1.Immediately disconnect the DC
switch and check the voltage.
2.Contact Growatt.
Warning 210
PV Reversed
1.Check PV input terminals.
2.Contact Growatt.
Warning
Description
Suggestion
Warning 219
PID function abnormal
1.Restart inverter.
2.If error message still exists,contact
manufacturer.
Warning 220
Sting DisConnect
1.Check string Connect is normal.
2.If error message still exists,contact
manufacturer.
Warning 221
Sting Current Unblance
1.Check Pv panel is normal.
2.If error message still exists,contact
manufacturer.
Warning 303
Output overload
1.Reduce the output power.
2.Contact Growatt.
Warning 304
CT open circuit
1.Check CT wiring.
2.Contact Growatt.
Warning 305
CT is reversed
1.Check if the CT wiring is reversed.
2.Contact Growatt.
Warning 306
CT communication failed
1.Check CT communcation wiring.
2.Contact Growatt.
Warning 307
Wireless CT pairing timed out
1.Check communcation wiring.
2.Contact Growatt.
Warning 308
Meter open circuit
1.Check meter wiring.
2.Contact Growatt.
Warning 309
The meter reversed
1.Check if the meter wiring is reversed.
2.Contact Growatt.
Warning 310
Ground zero detection
abnormal
1.After shutdown, Check whether the
ground wire is connected well.
2.Contact Growatt.
Warning 400
Fan function abnormal
1.After shutdown,Check the fan
connection.
2.Replace the fan.
3.Contact Growatt.
Warning 401
Meter abnormal
1.Check if the communication between
the inverter and the meter is abnormal.
2.Check if the meter is on.
Warning 402
The communication between
the optimizer and the inverter
is abnormal
1.Check if the optimizer is turned on.
2.Check the connection between the
optimizer and the inverter.
Warning 403
String abnormal
1.After shutdown,check the panel is
normal.
2.Contact Growatt.
Warning 404
EEPROM abnormal
1.Restart inverter.
2.Contact Growatt.
