Wall
Sunshade board
Rubber plate
Installation procedure:
3)
Installation assistance:
Horizontal line
- 12 -
1)
2)
6-10mm
Support
Remove the sticker from the front panel.
Put the unit into the installation hole.
Fill up sews in the cabinet with sponge or foam.
Use iron support
The installation hole should be strong enough to
support the air conditioner. If it cannot, iron sup-
port has to be used outdoors.
Iron support should be fixed on the building (Shown
at right figure.)
Use sunshade board
Air conditioner should avoid anything to be dropped
into it and avoid direct sunshine. If there is no cover
on it, you shou
ld contact the seller for installing
the sunshade board. When installing the sunshade
board, don’t let it block the air inlet at the side grille.
When installing the unit, it should be slante d
down to the back to avoid the enlargement of
noise or vibration. (Slant between 6-10mm.)
(Shown at right figure.)
The installation place should be strong enoug h
to avoid the enlargement of noise or vibration.
