5. Screw or nail cabinet wooden frame using shims if
frame is oversized, to eliminate
distortion. Remember to maintain proper slope as described in Step 3.
Support brakcet
Wooden strip
Refer to Step 4 of Window Mounting for assembly of
support brackets.
A wooden strip nailed to the
outside wall should be used in conjunction with sill support
angle brackets .
FIG.2
1"LONG
WOOD SCREW
4. Secure bottom rail to wood frame with two large wood
screws 1 "(2.5 cm)long using the two holes
in the bottom of the channel resting on frame.(See FIG.2 following
)
FIG.1
3/4"PLUS
TRIM THICKNESS
5/16 "
SEE PARA 5
LEVEL
TO
3/8"
2. Place cabinet into opening with bottom rail resting
firmly on bottom board of wooden frame.
3. Position cabinet to achieve proper slope for water removal .
(See FIG.1 below.
)
1. Slide chassis from cabinet. Refer back to Step 1 of
Window Mounting
.
NOTE: If w all thickness is 8-1 /2" or more, add aluminum
flashing over bottom of frame opening to
r
can enter area between inner and outer wall.
CAULK AS
ALUMINUM FLASHING
OVER
REQUIRED
OVER BOTTOM OF FRAME
81/2"
Prepare and Install Cabinet
assure no wate
