25
2. Install the supporter to the tripod with screw; clamp the supporter at the
and the unit with screw.
left tripod
supporter
type F screw
right tripod
3. Adjust the position of screw connecting the tripod and supporter into order
(Note: The outer case should be placed inclined outwards slightly.)
horizontal or inclined about 3-5°
3-5°
Can be moved
vertically to
adjust the
gradient of
outer case.
type E screw
supporter
outer case
