EN
INSTRUCTION MANUAL
ASSEMBLY
There is a rotation jet head at the upper cover, the water is passing from bottom to the jet head to make the
robot moving. While facing obstacle, the jet head turns around 180 degrees, the robot rounds the obstacle
and moving by another line. The rubbish is collected and installed by the bottom filter cabine.
ASSEMBLY AND OPERATION
•
Note:
Once the robot starts charging, the indicator light on the external adapter will turn red. When the robot is
fully charged, the indicator light will turn green.
Power on
A
B
B-1
E
C
D
Turn on the switch, loosen the rope on the float,
put the robot horizontally into the pool, and wait
for the robot to sink freely to the bottom. (if the
product is not put into the water, the machine will
not rotate because the machine has the function
of “stop when leaving water”).
Adjust the length of the rope to ensure that the
length of the rope is at the same height as the
water level, and the extra length of the rope is
tied or cut short.
A: Floater
B: Upper cover
B-1: Jet head
C: Filter
D: Bottom base
E: Charger
1 2
Charging warning
• Use only the original external adapter and
the charging cable provided.
• Make sure the robot and charger ports are
clean and dry before installation.
• Power up the robot before using it for the
first time (about 4-5 hours)
EN
