EN
ASSEMBLY AND OPERATION
There is a rotation jet head at the upper cover, the
water is passing from bottom to the jet head to make
the robot moving. While facing obstacle, the jet head
turns around 180 degrees, the robot rounds the
obstacle and moving by another line. The rubbish is
collected and installed by the bottom filter cabine.
INSTRUCTION MANUAL
ASSEMBLY
A: Floating foam.
(Use it when climbing the slope diffi-
cultly, or when the machine is upside
down)
B: Upper cover
C: Cartridge filter
(ONLY assembling it while small mi-
cro dust cleaning needed)
D: Filter
E: Bottom base
F: Charger
G: Hook
Charging warning:
• Only use the external adapter and the charging
cable provided.
• Make sure that the robot and charger ports are
clean and dry before installation.
• Power up the robot before using it for the first
time (about 5 hours)
1. Please turn off the robot before charging
2. Take the pin cover off before charging.
3. Plug the charger into the charging port, then start
to charge.
Note: Once the robot starts charging, the indicator light
on the external adapter will turn red. When the robot is
fully charged, the indicator light will turn green.
4. After charging, put the pin cover back on the
charging port. Make sure that the pin cover is fully
sealed before submerging in the water.
Bottom cover body assembly
Switch
Pin cover
Charging pot
Charger
B
A
C
D
E
F G
TOP
TOP
TO
P
TO
P
TOP
Step3 Step4
Step5
Step2
Step1
( ONLY assembling it while small
micro dust cleaning needed )
( Use it when climbing the slope
difficultly, or when the machine is
upside down )
TOP
TOP
TO
P
TO
P
