6
Nazwisko i adres osoby mającej miejsce zamieszkania lub siedzibę w
UE upoważnionej do przygotowania dokumentacji technicznej:
Podpisano w imieniu:
Grupa Topex Sp. Z o.o. Sp.k.
Ul. Pograniczna 2/4
02-285 Warszawa
Paweł Kowalski
Pełnomocnik ds. jakości firmy GRUPA TOPEX
Warszawa, 2022-07-11
EN
TRANSLATION OF ORIGINAL INSTRUCTION
58GE128
CAUTION: BEFORE USING THE TOOL READ THIS MANUAL
CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.
SAFETY REGULATIONS
This is not a toy. Children should not be permitted to use it. All electronic
parts are fixed already, any intention of opening work light or changing
work-light design is prohibitive unless a professional electrician. The light
source of this luminaire is not replaceable. When the light source reaches
its end of life, the whole luminaire shall be replaced.
Do not attempt to replace or change the diode lights! If the protective glass
is cracked or broken, it must be replaced before the work light can be used
again.
SYMBOLS EXPLANATION
Conforms to relevant EU standards.
To reduce the risk of injury, user must read instruction
manual.
DESCRIPTION OF GRAPHIC ELEMENTS
1.Handle
2.Frame
3.Logo
4.antenna
5.Display
6. button to select the saved station
7. button to select the saved station
8.Settings button
9.TUNE- / rewind
10.Przycisk on/off
11.Mode button
12.Select/Stop button
13.button to select a saved station
14. button to select the saved station
15.TUNE+ / fast forward
16.Search button
17.button INFO/MENU
18.alarm button
19.speaker
20.AUX port
21.18V/1,3A DC power cord input
22.USB charging port 5V/1A
23.battery charger
24.phone holder
25.rear cover
26.fastening
DESCRIPTION
• DAB+ receiver (174MHz - 240MHz)
• FM receiver (87.5MHz - 108.00MHz)
• Stores 30 FM presets
• Stores 30 DAB+ presets
• Quick preset Slot:4
• Bluetooth 5.0
• Powered by 2Ah/4Ah/6.0 Battery (not included)
• 18V mains adapter (included)
• Auto adjusting clock
• Dual Alarms
• 2.4' Color Display
• Dimmable Display
• Stereo Speaker(2x15W)
• 3.5mm AUX port (Line-In)
• Sleep function
• Multi Language Support
• Flexible Soft aerial
• Carry Handle
• Up to 10-20hours constant play using battery pack
• Bluetooth Mode
Activate the Bluetooth function using the "mode" button until the Bluetooth
icon appears. Activate the bluetooth on your device and search for
available devices. Look for and add “RADIO” The radio will automatically
pair with the device and no code is required. The display will show
"Connected' if the pairing is successful.
•FM Mode
Press MODE key and choose the FM mode, press “OK” key confirm.
To auto tune to the next available radio station press and hold either Tune
+/-' buttons for 3 seconds. This will start the FM auto scan.
'+' will scan up the channel and will scan down the channel.
The scan will always stop at the next signal received. Save as a preset if
required
•DAB+ Mode
Press MODE key and choose the DAB+ mode, press SELECT key to
confirm. Use the tune +/- buttons to cycle through the available DAB+
stations on the display. Press the dial to tune the radio into the station that
is shown on the display.
CONTENTS
• DAB+ / FM Radio - 1 pc
• 18V/1,3A power supply - 1 pc
• user manual - 1 pc
• technical documentation - 1 pc
• guarantee card – 1 pc
OPERATING
Control Method
• On/Off/Standby
Press the power button to turn the radio on. Once on press it again
to enter standby mode or hold it to turn the radio off.
• Using The Buttons
All the button actions are just a quick press unless otherwise stated
in the required action. This includes the button function of the dial.
• Using The Dial
The dial on this radio is dual action. This means it will perform one
action by turning the dial and another action by pressing it.
Setup
• First Time Use
After removing the radio from the packaging, connect the radio to the
mains using the adaptor supplied or 2Ah/4Ah/6.0 Battery
into the battery compartment in the base. Fully extend the aerial and press
the power button to turn the radio on.
The date and time will automatically be set from the DAB+ signal received.
The radio will then proceed to scan for the first time.
The number to the right of the display indicates the amount of channels
found in your region during this scan. After the scan is complete the radio
will tune itself to the first alphabetically listed station available in DAB+
mode.
DAB+ Mode
Press MODE key and choose the DAB+ mode, press SELECT key to
confirm.Use the tune +/- buttons to cycle through the available DAB+
stations on the display. Press the dial to tune the radio into the station that
is shown on the display.
• Scan
You can retune or refresh the amount of DAB+ stations available by
pressing the "Scan' button. It is recommended you do this when the radio
has been moved or if you are getting a poor DAB+ signal.
DAB+ Options
• DAB+ Menu Options
Press and hold the 'Info/Menu' button until you see "Full Scan'.
Press the tune +/- buttons to cycle the options and press the dial to select.
The options here are:
Full Scan > Manual Tune > DRC > Prune >Preset >System
• Full Scan
To fully erase and retune all of the available DAB+ stations select 'Full
Scan' in the menu options.
The radio will now scan through all the available channels.
