Setup
3B0283E 11
Setup
EVO and EVO Plus
1. Unscrew Cup from Spray Head. Make
sure the Suction Tube is installed.
NOTE: For spraying upwards, place the end
of the Suction Tube pointing backward. For
spraying downwards, place the end of the
Suction Tube pointing forward.
2. Place the included strainer on the Cup.
Pour paint through the strainer until
paint is level with the top hash mark.
NOTE: If the paint stops draining, but the
Cup is not full, use a stir stick to scrape the
captured paint at the bottom of the strainer
until the paint resumes draining.
3. Firmly tighten the Cup to the Spray
Head.
NOTE: For easy install, place the Cup on a
level surface, then screw the Spray Head
onto the Cup.
4. Attach the Spray Head to the Turbine.
Place the Turbine at a 90 degree angle to
the Spray Head. Connect the Spray
Head and Turbine, then turn clockwise
until it clicks into place. The Turbine
should be in line with the Spray Head.
