13

11 Specifications

GAIN RANGE (Instrument Input to DI Output)

MIC In, DI Line, Insert pad 0dB, Boost 0dB +0.6dB to +55.1dB

MIC In, DI Mic, Insert pad 0dB, Boost 0dB -24dB to +30.5dB

Inst In, Low Gain, DI Line, Insert Pad 0dB, Boost 0dB -13.4dB to +41.1dB

Inst In, High Gain, DI Line, Insert Pad 0dB, Boost 0dB +0.6dB to +55.1dB

Boost 0-11.5dB

GAIN RANGE (Input to Amp Out )

MIC In, DI Line, Insert pad 0dB, Boost 0dB, Amp Out Max +9.3dB to +63.9dB

Inst In, Low Gain, DI Line, Insert Pad 0dB, Boost 0dB, Amp Out Max -4.7dB to +49.9dB

Inst In, High Gain, DI Line, Insert Pad 0dB, Boost 0dB, Amp Out Max +9.3dB to +63.9dB

Boost 0-11.5dB

THD+N 1kHz, 22Hz-22kHz BW (MIC Input to Amp Output)

@ 18dB Gain +10dBu out <-103dB

@ 38dB Gain +10dBu out <-97dB

@ 58dB Gain +10dBu out <-80dB

@ 69dB Gain +10dBu out (boost at max) <-73dB

INTERMODULATION DISTORTION - SMPTE/DIN 4:1 7kHz/50Hz (MIC Input to DI Output)

@ 40dB Gain +10dBu out < 0.070%

INTERMODULATION DISTORTION - SMPTE/DIN 4:1 7kHz/50Hz (MIC Input to Amp Output)

@ 38dB Gain +10dBu out <0.0020%

NOISE - REFERRED TO INPUT MIC In 20Hz-22kHz BW 50Ω source

Mic IN to DI-Line level out 55.1dB Gain -130dB

Mic IN to Amp Out -130dB

CMRR @40dB Gain

100Hz > 50dB

1kHz > 80dB

10kHz > 80dB

CMRR @60dB Gain (55db + 5dB Boost)

100Hz > 50dB

1kHz > 80dB

10kHz >90dB

FREQUENCY RESPONSE (Input to DI Output)

Mic input @ 0.5dB Gain -3dB 6Hz-63kHz

Inst input @ 20dB Gain -3dB 15Hz-65kHz

I/O IMPEDANCE

CH1 MIC Input 8.1kΩ

CH1 Inst Input 1.0MegΩ

Insert Input 10kΩ

DI Outputs 150Ω

Amp, Tuner, Headphone and Insert Outputs 500Ω

SIGNAL / PEAK LED METER

Green threshold -16dBu

Red threshold +7dBu

MAXIMUM INPUT LEVEL

CH1 MIC +17.5dBu

CH1 Inst High Gain: +17.5dBu

High Gain: +21.5dBu

MAXIMUM OUTPUT LEVEL - 100k Ohm load, 0.1% THD

DI Outputs Line: +19.7dBu

Mic: -4.8dBu

Amp Out Balanced +22.0dBu

Tuner Out Unbalanced +21.6dBu

HIGH PASS FILTER / NOTCH FILTER

High Pass Filter 75Hz -3dB @ 78Hz

High Pass Filter 150Hz -3dB @ 153Hz

EQ

Gain +/-10dB

Low Frequency Low Range: 125Hz Shelving

High Range: 250Hz Shelving

Mid Frequency 275Hz – 3.6kHz

Mid Frequency Q 1.2

High Frequency High Range: 2kHz Shelving

Low Range: 1kHz Shelving

OUTPUT NOISE 22Hz-22kHz BW

CH1 MIC Input (50 ohms) to DI Output (Line) < -95dBu

CH1 Inst Input (50 Ohms) to DI Output (Line) < -95dBu

CH1 MIC Input (50 ohms) to DI Output (Mic) < -115dBu

CH1 Inst Input (50 Ohms) to DI Output (Mic) < -115dBu

POWER CONSUMPTION

100-240VAC 50/60Hz 10 Watts Max

9V DC OUTPUT

2.1mm, Center Negative 9V, 500mA MAX

WEIGHT and DIMENSIONS

3.2lbs H3.0” x W6.2” x D5.5”
