10

10.2 CONNECTION DIAGRAM

PUSH

1

2

3

ROXi connections

Nothing too terribly hard and fast here - just the basics about how to plug stu in and out of your

preamp. INPUT paths are shown in blue. OUTPUT paths are shown in red.

There are many ways to setup your preamp, so if you aren’t sure about how something works, please

have a look at your owner’s manual, check out our website - www.gracedesign.com - or feel free to

call us. We are always glad to help out in any way we can. 1.303.823.8100, M-F, 9-5 MST

eects are routed through

the FX insert IN and OUT

stage amp is fed by amp out

PA system / mixer is fed by DI output

stage tuner is

fed by tuner out

100 ~ 240 VAC power

9VDC OUT on

the side panel

powers your

pedals

Your microphone

or instrument

plugs into to ROXi

Mr. Amp

reverb

out input

fuzzz

out

input

tuner

out input

A
