LABKON Series
_________________________________________________________________________________________________
22 GMC-I Messtechnik GmbH
Flow Control:
*On Off
Flow Control:
*On Off
USB Interface
None
Selecting USB
GPIB Interface
GPIB Address:
5
GPIB Address：
Address Value
Notes: Except the parameters about knob, key sound and interface configuration, other parameters in the main menu will not
be saved when the power supply is switched off. If you would like to store relevant parameters, please press “2nd” + “Save”
keys or make use of *sav command.
3.6 Storing and Recalling
Store and recall procedures are illustrated in the following:
1 Press “2nd” + “Save” keys to enter the electronic store menu, or press “2nd” + “Recall” keys to enter the electronic recall
menu.
2 Press keys or adjust the knob to select store or recall location (0~9).
3 Press “Enter” key to confirm and exit store or recall menu simultaneously. For a store case, voltage and current values are
saved in corresponding EEPROM and for a recall condition, the voltage and current values stored previously can be
retrieved from corresponding EEPROM and set as present values.
Example 1: Set voltage to 5V and current to 2A. Then turn on the power supply and save this state to the EEPROM specified
by Location 1.
Step
Operational Details
Display Information
1
Set voltage to 5V and current to 2A. Then turn on the
power supply.
5.000V 2.000A
0.000W CV
2
Press “2nd” + “Save” keys to enter into store menu.
Save：0
3
Press keys or adjust the knob to select store location as 1.
Save：1
4
Press “Enter” key to confirm and exit store menu
simultaneously.
5.000V 2.000A
0.000W CV
Example 2: Based on Example 1, set voltage to 30V. Then turn off the power supply and recall the values saved in the
EEPROM specified by Location 1.
Step
Operational Details
Display Information
1
Set voltage to 30V. Then turn off the power supply.
30.000V 0.000A
0.000W OFF
2
Press “2nd” + “Recall” keys to enter into recall menu.
Recall：0
3
Press keys or adjust the knob to select recall location as 1.
Recall：1
4
Press“Enter” key to confirm and exit recall menu
simultaneously.
5.000V 2.000A
0.000W CV
