THE INSTRUMENT

13 | 71 ENERGYMID

5.5 TAMPER-PROOF SEALING

The instrument is provided with various seals in order to protect it against unauthorized modifications.

One manufacturer’s seal on the side:

Four tamper-proof seals for the terminal cover (can be mounted to the left and right of each terminal cover):

5.6 CONNECTIONS

Fig. 4: Instrument – Connections

The manufacturer’s seal serves as the instrument’s calibration and guaran-

tee seal.

ATTENTION

Violation of Calibration Law

An instrument with a broken manufacturer’s seal may not be used for billing

purposes.

Never break or damage the manufacturer’s seal.

Manufacturer’s

Seal

Sealing Eyelet, Side View:

Sealing Eyelet

Enable Key

Tariff Connections

Pulse Output or Bus

Connections

(feature-dependent)

Current and

Voltage Connections

Terminal Cover

(open)

Terminal Cover

(open)

Terminal Labeling

(feature-dependent)

Terminal Labeling

(feature-dependent)

In Case of Z2: Additional

MessEV Conformity Marking
