Dimensions
Flush-mount
X1JII1HGG1FEDCBAHob
Width
22≥ 10560604≥ 600490524230424655752060060 cm
42≥ 10750834≥ 600490524230424655752083083 cm
INFORMATION!
The countertop must be strong enough to ensure the safe use of the hob. If in doubt, consult
the countertop manufacturer.
Flush-mount
The appliance may only be installed into a temperature- and water-resistant countertop, such as a
countertop made of (natural) stone (marble, granite), or solid wood (the edges along the cut-out have
to be sealed). When installing into a countertop made of ceramics, wood, or glass, a wooden sub-frame
should be used. The frame is not supplied with the appliance. The appliance may only be installed
into a countertop made of other materials after you have consulted the countertop manufacturer and
obtained his express approval. Internal dimension of the basic unit should be at least equal to the
internal cutout for the appliance. This will allow simple removal of the appliance from the countertop.
Install the appliance (see ‘Built-in’) and connect the appliance to the mains power supply (see 'Electrical
connection'). Test the operation of the appliance before applying the seal. Seal the groove between
the appliance and the kitchen worktop with a silicone sealant. The silicone sealant used to seal the
appliance must be temperature-resistant (to at least 160 °C). Smooth out the silicone sealant using
suitable tools. Observe the instructions for use of the selected silicone sealant. Do not switch on the
appliance until the silicone sealant has dried completely.
1. Silicone sealant, 2. Sealing tape
INFORMATION!
Pay particular attention to built-in dimensions with (natural) stone countertops. When choosing
the silicone sealant, observe the countertop material and consult the countertop manufacturer.
Use of inappropriate silicone sealants can result in permanent discolouration of some parts.
14
