14
Place the wire guides with the catalytic inserts on the upper openings in the side walls of the oven “A“.
Press them into the snap lock at the bottom “B“.
Do not wash the catalytic inserts in the dishwasher.
REPLACING THE BULB
The bulb is a consumable and therefore not covered by warranty. Before changing the bulb, remove the trays, the grid,
and the guides.
Disconnect the appliance from the power mains!
Halogen lamp: G9, 230 V, 25 W. (regular bulb E14, 230 V, 25 W - depending on the model)
A Undo the bulb cover and pull out or undo the bulb.
Use protection to avoid burns.
B Use a flat screwdriver to release the bulb cover and remove it. Remove the bulb.
Be careful not to damage the enamel.
COMFORT DOOR CLOSING (depending on the model)
Cookers are equipped with new secure door hinges COMFORT. These special hinges guarantee very quiet and gentle
closing of the oven door.
If the force applied to close the door is too strong, the efficiency of the system can be reduced or the
system's safety can be affected.
DOOR LOCK (depending on the model)
Open the door lock by gently pushing it to the right with your thumb while simultaneously pulling the door outwards.
When the oven door is closed, the door lock automatically returns to the initial position.
REMOVING AND REPLACING THE OVEN DOOR (depending on the model)
• Open the oven door (up to end position).
• Rotate the flaps of door hinges (in case of conventional closing). At COMFORT soft closing system, rotate the flaps
by 90°.
• Slowly close the oven door until the flaps fit together with the hinges in the side laths of the door. At the angle of
15° (regarding to the closed door position), slightly close the door and pull it out from both hinges of the appliance.
