STANDARD INSTALLATION MANUAL FOR POLARIS 580W (HOOP INSTALLATION)
FIGURE 15
● Place the second product's right side tightly against the left frame of the rst product and
align the top and bottom edges with those of the rst product (Figure 13)；
● Install the left-side suppo tting assembly below the product (Figure 13). Place the bottom
fastener assemblies into the groove of the product frame, and place the square plate at the
opening of the hoop. Tighten the nut to x the assembly onto the purlin. Similarly, install the
right-side suppo tting assembly (as shown in Figure 14). At this point, the rst product has
been installed.
● For the installation of the second product, rst place upper fastener assemblies and
mounting suppo in position (as shown in Figure 15). The distance between the two upper
fastener assemblies is still 1147mm, and the two bottom fastener assemblies are still located
between the two mounting suppos.
Upper fastener assemblies
Bottom fastener assembliesMounting suppo
