06 Electrical Connection
21
User Manual V1.2-2025-01-16
L1L2L3
N PE
3
1
2
1
1
2
M6 3-5N·m
M8 7-10N·m
M12 25-30N·m
3
3
2
1
M5 2-3N·m
M5 2-3N·m
1 432
WARNING
• Make sure to connect the AC cable wires to the corresponding terminals on the inverter to
avoid any damage to the equipment
• Make sure that the whole stripped length of the wire is inserted into the terminal hole. No
part of the wire core should be visible.
• Make sure that the cables are connected securely. Otherwise, the terminal may be too hot
to damage the inverter when the inverter is working.
• The AC terminals are compatible with three-phase four-wire or three-phase ve-wire grid.
The actual wiring method may be dierent. The gure below takes the three-phase ve-
wire as an example.
• Keep extra slack for the PE wire. Make sure that would be the last one to bear stress when
the AC output cable is under tension.
• Please prepare OT terminals for AC cable connection. Use copper to aluminium adapter
terminals when using an aluminium cable.
Step 1: Crimp the AC cable OT terminal, and prepare the AC output cable.
Step 2: Remove the AC terminal cover.
Step 3: Fasten the AC output cable to the inverter.
Step 4: Tighten the AC terminal cover, and fasten the plastic cover.
Cu
Al
Cable
Material
Cable
Type
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
H
(mm)
I
(mm)
S
(mm
2
)
Cu
S
C+2mm
I
Al
S
3 - 5.5 8.5 - 16
12 - 22
35 - 150
16
- 70
50 - 150
3.5 - 6 8.5 - 16
14 - 25
3.5 - 5 7 - 13
12 - 21
8.5 - 9
3 - 4.5 7 - 13
10 - 18
8.5 - 9
6.5 - 7
L1|L2|L3
L1|L2|L3
N
PE
N
single-
core
cable
-
-
-
-
25 - 75
multi-
core
cable
single-
core
cable
multi-
core
cable
B
B
C
C
E
E
G
G
F
F
D
D
A
A
H
C+2mm
C+2mm
I
H
C+2mm
