10 Technical Data
85
Technical Data
GW25K-SDT-AU30
GW29K9-SDT-
AU30
Input
Max.Input Power (W) 37,500 45,000
Max.Input Voltage(V) 1100 1100
MPPT Operating Voltage Range (V) 140~950 140~950
MPPT Voltage Range at Nominal
Power (V)
*2
400~850 400~850
Start-up Voltage (V) 160
Nominal Input Voltage (V) 600 600
Max. Input Current per MPPT (A) 40/40/40
Max. Short Circuit Current per MPPT
(A)
56/56/56
Max.Backfeed Current to The Array(A) 0 0
Number of MPP trackers 3 3
Number of Strings per MPPT 2 2
Output
Nominal Output Power (W) 25,000 29,990
Nominal Output Apparent Power (VA) 25,000 29,990
Max. AC Active Power (W) 25,000 29,990
Max. AC Apparent Power (VA) 25,000 29,990
Nominal Output Voltage (V)
230/400, 3L/N/PE
or 3L/PE
230/400, 3L/N/PE
or 3L/PE
Output Voltage Range (V)
180- 260
(According to
local standard)
180- 260
(According to
local standard)
Nominal AC Grid Frequency (Hz) 50/60 50/60
AC Grid Frequency Range (Hz) 45~55 / 55~65 45~55 / 55~65
Max. Output Current (A) 37.9 45.5
Max. Output Fault Current (Peak and
Duration) (A)
126 @6.5us 126 @6.5us
Inrush Current (Peak and Duration)
(A)
48.12 @50us 48.12 @50us
Nominal Output Current (A) 36.3 @400Vac 43.5 @400Vac
