10 Technical Data
82
Technical Data
GW15K-SDT-AU30 GW20K-SDT-AU30
Input
Max.Input Power (W) 22500 30000
Max.Input Voltage(V) 1,100 1,100
MPPT Operating Voltage Range (V) 140~950 140~950
MPPT Voltage Range at Nominal
Power (V)
*2
210~850 300~850
Start-up Voltage (V) 160
Nominal Input Voltage (V) 600 600
Max. Input Current per MPPT (A) 32/32/16
Max. Short Circuit Current per MPPT
(A)
45/45/23
Max.Backfeed Current to The Array(A) 0 0
Number of MPP trackers 3 3
Number of Strings per MPPT 2/2/1 2/2/1
Output
Nominal Output Power (W) 15,000 20,000
Nominal Output Apparent Power (VA) 15,000 20,000
Max. AC Active Power (W) 15,000 20,000
Max. AC Apparent Power (VA) 15,000 20,000
Nominal Output Voltage (V)
230/400, 3L/N/PE
or 3L/PE
230/400, 3L/N/PE
or 3L/PE
Output Voltage Range (V)
180- 260
(According to
local standard)
180- 260
(According to
local standard)
Nominal AC Grid Frequency (Hz) 50/60 50/60
AC Grid Frequency Range (Hz) 45~55 / 55~65 45~55 / 55~65
Max. Output Current (A) 21.8 29.0
Max. Output Fault Current (Peak and
Duration) (A)
70 @6.5us 70 @6.5us
Inrush Current (Peak and Duration)
(A)
42.3 @50us 42.3 @50us
